MTI-milliren小型OCXO恒溫晶振205-0108,205-0112

發布時間：2025-07-24 08:58:40 瀏覽：2813

　　MTI-milliren公司生產的205系列是業內最為緊湊的OCXO(恒溫晶體振蕩器)。其密封封裝尺寸僅為0.815"L x 0.515"W x 0.394"H(20.7 x 13.1 x 10.0mm) 。在100°C的溫度范圍內，它提供±3.5E - 06的熱穩定性，在25°C時，預熱時間不到5分鐘，功耗小于0.45W 。1Hz時的相位噪聲為 - 160dBc/Hz，頻率范圍是8MHz至200MHz 。

MTI-milliren小型OCXO恒溫晶振205-0108,205-0112

205 Series Base Model Performance Guide
Frequency MHz	Crystal Cut	Thermal Stability*	Aging Rate per Day	Aging Rate per Year	Output	Phase Noise @offsets(dBc/Hz)
Frequency MHz	Crystal Cut	Thermal Stability*	Aging Rate per Day	Aging Rate per Year	Output	1Hz	10Hz	100Hz	1kHz	10kHz	100kHz
40.000	AT	±3.50E-06	5.00E-09	5.00E-07	7dBm Sine	-50	-80	-110	-140	-150	-160
50.000	AT	±3.50E-06	5.00E-09	5.00E-07	7dBm Sine	-50	-80	-110	-140	-150	-160
65.536	AT	±3.50E-06	5.00E-09	5.00E-07	7dBm Sine	-50	-80	-110	-140	-150	-160
77.760	AT	±5.00E-06	5.00E-09	5.00E-07	7dBm Sine	-45	-75	-105	-130	-140	-150
80.000	AT	±5.00E-06	5.00E-09	5.00E-07	7dBm Sine	-45	-75	-105	-130	-140	-150
100.000	AT	±5.00E-06	5.00E-09	5.00E-07	7dBm Sine	-45	-75	-105	-130	-140	-150

Short Term Stability	dF/dV	dF/dL	Warm Up		Warm Up Power (W)	Comtinuous Power (W)G25℃	Tuning(Min)	MTI Model#
Short Term Stability	dF/dV	dF/dL	Time(Min)	dF/F	Warm Up Power (W)	Comtinuous Power (W)G25℃	Tuning(Min)	MTI Model#
5.00E-10	5.00E-07	5.00E-07	5	2.00E-07	2.5	0.45	1.50E-05	205-0108
5.00E-10	5.00E-07	5.00E-07	5	2.00E-07	2.5	0.45	±5.00E-06	205-0109
5.00E-10	5.00E-07	5.00E-07	5	2.00E-07	2.5	0.45	±5.00E-06	205-0106
5.00E-10	5.00E-07	5.00E-07	5	2.00E-07	2.5	0.45	1.50E-05	205-0112
5.00E-10	5.00E-07	5.00E-07	5	2.00E-07	2.5	0.45	±5.00E-06	205-0107
5.00E-10	5.00E-07	5.00E-07	5	2.00E-07	2.5	0.45	±5.00E-06	205-0110
